WAREHOUSE ESSENTIALS SERIESNarrow Fork (Euro)
SESR15-N Electric Pallet Jack - Narrow Fork Size (21" X 47")
Narrow 21" forks for Euro pallets • same motor & capacity as the SESR15
Rs. 165,000.00 INR
Built to Order
Direct from Manufacturer
12-Month Warranty
Direct Support
At a Glance
3300 lb Capacity (1500 kg)
21.65″ × 45″ Fork Dimensions (OAW × L)
24V / 20Ah Lithium Battery
55″ Turning Radius
Currently built to order. 3300 lb capacity, 12-month warranty, factory-direct support across Canada. Request a quote to reserve.
Have questions? See FAQ ↓ Browse all electric pallet jacksManufactured and supported from our Bangalore facility (Jigani Industrial Area, Bengaluru, Karnataka).
Request a Quote
Get a formal quote with freight options in your inbox within 1 business day.
Trusted by Leading Canadian Operations Teams
Fit & Compatibility
Will it fit your facility?
Narrow 21.65 in (550 mm) forks designed for Euro and CHEP pallets. Check the critical dimensions before you order.
Footprint & Clearance
Turning radius
55 in
1,398 mm
Min aisle (1000x1200 pallet)
71 in
1,804 mm
Min aisle (800x1200 Euro pallet)
73 in
1,854 mm
Fork spread (outside)
21.65 in
550 mm
Overall length
63 in
1,603 mm
Fork length
45 in
1,150 mm
Ramp capability
Loaded
5%
Max safe incline
Unloaded
10%
Max safe incline
Pallet compatibility
- Euro pallet (800 x 1200 mm), primary
- CHEP pallet
- IOPP pallet
- ISO container pallet with narrow fork openings
Standard or Euro pallets?
The SESR15 and SESR15-N share the same chassis. Only the fork geometry differs.
✓ SESR15-N (EURO PALLETS)
21.65″ (550 mm) fork spread
- Euro pallets (800 × 1200 mm) — primary
- CHEP, IOPP, and ISO container pallets
- Import / export and international logistics
- Container loading with tight fork-entry windows
→ CONSIDER THE SESR15 (GMA PALLETS)
27″ (685 mm) fork spread
- Standard 40 × 48″ GMA pallets (North American standard)
- 4-way entry on open-bottom pallets
- Freight, retail, manufacturing, domestic logistics
- General single-shift warehouse operations
Same capacity (3,300 lb), same battery, same motor. Only difference: fork spread.
Why Upgrade
When you need more than the SESR15-N.
The SESR15-N is engineered for single-shift Euro-pallet operations. If your operation runs heavier loads, multiple shifts, or demands diagnostic visibility, the SELR20+ is the upgrade path.
Feature
SELR20+ (Plus Series)
SESR15-N (Warehouse Essentials)
Rated capacity
4,400 lb (2,000 kg)
3,300 lb (1,500 kg)
Battery
48V 30Ah LiFePO4
24V 20Ah LiFePO4
Warranty coverage
18 months
12 months
Diagnostic fault codes
Built-in
Standard
Daily duty cycle
Continuous, multi-shift
Single-shift, light to medium
Technician support
Priority Plus
Canadian direct
Compare the lineup
Compare All Electric Pallet Jacks
Need more capacity or multi-shift uptime? The SELR20+ is the recommended upgrade with 33% more capacity, 18-month warranty, and priority support.
SESR15
Standard forks for North American GMA pallets
Rated Capacity
3,300 lb (1,500 kg)
Fork Dimensions
45" L × 27" W
- Battery System: 24V 20Ah lithium-ion
- Charger Input: 120V (standard outlet)
- Fits standard 40×48" GMA pallets
- 20Ah battery for light daily throughput
- 120V charging, standard outlet
Designed For
Single-shift warehousing, light-to-medium daily throughput, facilities using 40×48" GMA pallets.
Not Recommended
Euro pallets (forks too wide), heavy daily loads over 3,000 lb, operations requiring integrated weighing.
View Model Details
Standard
SELR20
Standard single-shift warehouse use
Rated Capacity
4,400 lb (2,000 kg)
Fork Dimensions
45" L × 27" W
- Battery System: 48V 30Ah lithium-ion
- Charger Input: 120V (standard outlet)
- 33% more capacity than SESR15
- Wider fork base for greater stability
- 30Ah battery for extended daily operation
Designed For
High-volume distribution centers, heavy daily loads, operations moving 3,500–4,400 lb pallets regularly.
Not Recommended
Euro pallets, facilities with tight aisle clearances.
View Model Details
SESR15-N
Narrow forks for Euro pallets and tight aisles
Rated Capacity
3,300 lb (1,500 kg)
Fork Dimensions
45" L × 21.65" W
- Battery System: 24V 20Ah lithium-ion
- Charger Input: 120V (standard outlet)
- Optimized for Euro pallets (800×1200mm)
- Narrow fork profile for tighter aisles
- Same motor and capacity as SESR15
Designed For
Euro pallet operations, import/export facilities, international logistics, confined aisles.
Not Recommended
Standard GMA pallets (forks too narrow), operations requiring wider fork support.
View Model Details
SELR20-S
SELR20 power with integrated scale for weighing
Rated Capacity
4,400 lb (2,000 kg)
Fork Dimensions
45" L × 27" W
- Battery System: 48V 30Ah lithium-ion
- Charger Input: 120V (standard outlet)
- Built-in electronic scale for freight verification
- Real-time weight data during pallet handling
- Eliminates need for separate floor scales
Designed For
Shipping/receiving docks, freight compliance, operations requiring documented weight data.
Not Recommended
Facilities not requiring weighing (SELR20 is more cost-effective), Euro pallet operations.
View Model Details
Technical Specifications
Complete engineering data.
Dimensions
Overall length
63 in (1,603 mm)
Fork spread (outside)
21.65 in (550 mm)
Turning radius
55 in (1398 mm)
Service weight
313 lb (142 kg)
Pallet
65 × 40 × 55 in (1.65 × 1.02 × 1.40 m)
Shipping weight
360 lb (163 kg)
Power system
Battery type
Lithium LiFePO4
Voltage / capacity
24V / 20Ah
Charger input
120V / 60Hz
Charger output
24V / 10A
Charge time
4–5 hours
Performance
Rated capacity
3300 lb (1500 kg)
Travel speed (loaded)
2.6 mph (4.2 km/h)
Gradeability
5% loaded / 10% unloaded
Compliance
CE certified
Yes
Warranty
12 months
Service & Support
Replacement Parts in Stock
Stocked in Canada and ready to ship. Keep your unit running for years.
- Stocked in Canada
- Order direct
- DIY-friendly
- Local mechanic compatible
- Or drop it off to us
Total Cost of Ownership
Pays for itself in months, not years.
Manual pallet movement adds time to every Euro-pallet run. In single-shift warehouses moving 20–50 pallets a day, the SESR15-N is the lowest-capital-cost way to put electric movement under narrow-entry pallet handling.
Time per pallet
60 sec saved
vs. manual jack
Cost per pallet
$0.09
5-year TCO, all-in
Typical payback
1 to 5 mo
in single-shift use
Step up to SELR20
+$550
for 4,400 lb capacity
Payback Calculator
Calculate your payback.
Annual labour recovered
$0/yr
Payback period
-
Assumes $28/hr fully-loaded operator cost, 250 operating days, 60s saved per pallet.
Frequently Asked Questions
Battery & Uptime
How long does the battery last per charge?
Runtime varies by load and usage. Under typical single-shift warehouse conditions (20–50 pallets/day), the 24V 20Ah lithium-ion battery handles a full shift.
How long does it take to fully charge?
Approximately 4–5 hours from empty using the included 120V charger. No special wiring or outlet required. Plug into any standard North American wall outlet.
Can I swap batteries quickly?
Yes. The lithium-ion battery is removable and designed for tool-free swaps. With a second battery on hand, swapping takes under a minute.
Fit & Operation
Does the SESR15-N fit Euro pallets?
Yes. The 21.65″ (550 mm) fork outside width is sized for Euro 800×1200 mm pallets, CHEP pallets, IOPP pallets, and ISO container pallets with narrow fork-entry windows.
Can I use GMA pallets with the SESR15-N?
No. The 21.65″ (550 mm) fork spread is too narrow for standard 40×48″ GMA pallets. For GMA, see the SESR15 standard-fork model with a 27″ (685 mm) spread.
Can this replace a manual pallet jack completely?
For most single-shift Euro-pallet operations, yes. The SESR15-N eliminates manual pumping and reduces operator fatigue across 8-hour shifts.
Can I use it inside trucks, trailers, or ISO containers?
Yes. The compact 63" × 27" footprint combined with the narrow 21.65" fork spread makes the SESR15-N especially well-suited for ISO container loading and unloading where fork-entry windows are tight.
Delivery & Support
What's the lead time on the SESR15-N?
Approximately 45 business days from order confirmation. The SESR15-N is a lower-volume narrow-fork variant and sells through the quote path. Request a quote to reserve a production slot.
What's delivery like (liftgate, appointment)?
Delivered via LTL freight on a pallet. Liftgate and appointment delivery may be available depending on carrier and location. Contact us for a delivery quote with exact options for your facility.
Do you stock parts in Canada?
Yes. We maintain replacement parts inventory at our Ontario warehouse. Common items like batteries, chargers, wheels, seals, and controllers typically ship within 1–3 business days.
What's included in the warranty?
1-year warranty covering the drive motor, hydraulic system, controller, and battery against manufacturing defects. Canadian-based parts availability and responsive support. Claims are handled directly. No third-party runaround.
Can I order multiple units?
Yes. Contact us at 844-861-9484 or sales@sumachay.com to discuss your requirements. Each unit ships individually via LTL freight and pricing is per unit.
